Parameters Description Unit
Machining
direction
● Face
● Longitudinal
X0 Reference point ∅ (abs) mm
Z0 Reference point (abs) mm
X1 End point X ∅ (abs) or end point X in relation to X0 (inc) mm
Z1 End point Z (abs) or end point Z in relation to X0 (inc) mm
FS1...FS3 or R1...R3 Chamfer width (FS1...FS3) or rounding radius (R1...R3) mm
XF2 Undercut (alternative to FS2 or R2) mm
D Infeed depth (inc) – (for roughing only) mm
UX Final machining allowance in X direction (inc) – (for roughing only) mm
UZ Final machining allowance in Z direction (inc) – (for roughing only) mm
Execution in manual mode
5.8 Simple workpiece machining operations with milling/turning machines
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 187
