Unloading tools
1. Place the cursor on the tool that you would like to unload from the mag‐
azine and press the "Unload" softkey.
2. Select the required load point in the "Loading Point Selection" window.
3. Confirm your selection with "OK".
- OR -
Undo your selection with "Cancel".
13.5.7 Selecting a magazine
You can directly select the buffer memory, the magazine, or the NC memory.
Procedure
1. The tool list is opened.
2. Press the "Magazine selection" softkey.
If there is only one magazine, you will move from one area to the next
(i.e. from the buffer memory to the magazine, from the magazine to the
NC memory, and from the NC memory back to the buffer memory) each
time you press the softkey. The cursor is positioned at the beginning of
the magazine each time.
- OR -
If there is more than one magazine, the "Magazine Selection" window
opens. Position the cursor on the desired magazine in this window and
press the "Go to" softkey.
The cursor jumps directly to the beginning of the specified magazine.
Hiding magazines
Deactivate the checkbox next to the magazines that you do not want to appear in the
magazine list.
Tool management
13.5 Tool list
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 707
