Page #833 background image
16.2 Measuring the tool
All the options of the manual and automatic measurement are available to determine the tool
offset data (see also Section "Measure tool (Page 100)").
Procedure
1. "Manual Machine" is active.
2. Press the "Meas. tool" softkey.
3. Select the the required measuring function in the vertical softkey bar and
press the appropriate softkey.
Working with Manual Machine
16.2 Measuring the tool
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 833
