9.17 Measuring cycle support
Measuring cycles are general subroutines designed to solve specific measurement tasks. They
can be adapted to specific problems via parameter settings.
Software option
You require the "Measuring cycles" option to use "Measuring cycles".
References
You will find a more detailed description on how to use measuring cycles in:
Programming Manual Measuring cycles / SINUMERIK 840D sl/828D
Creating a ShopMill program
9.17 Measuring cycle support
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 353
