21.3 Activating and deactivating a device
Status Meaning
Device activated
System waiting for PLC checkback signal
Device faulty
Interface error in the communication module
Procedure
1. Easy Extend is opened.
2 You can select the desired device in the list with the <Cursor down> or
<Cursor up> keys.
3. Position the cursor on the device option for which the function has been
unlocked and press the "Activate" softkey.
The device is marked as activated and can now be used.
4. Select the desired activated device and press the "Deactivate" softkey to
switch the device off again.
Easy Extend
21.3 Activating and deactivating a device
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 893
