14.17 Setup data
14.17.1 Backing up setup data
In addition to programs, you also have the option of saving tool data and zero point settings.
In this way you secure the required tools and zero point data for a specific machining step
program. If you want to execute this program at a later point in time, then you can quickly
access the relevant settings.
Even tool data that you have measured on an external tool setting station can be copied easily
into the tool management system using this option.
Backing-up job lists
If you wish to backup a job list, which contains ShopMill and G code programs, you obtain
dedicated selection boxes to backup the tool data and zero points.
Note
Backing up setup data from part programs
Setup data from part programs can only be backed up if they have been saved in the
"Workpieces" directory.
For part programs, which are located in the "Part programs" directory, "Save setup data" is
not listed.
Backing up data
Data Setting options
Tool data
● No
● All used in the program (only for ShopMill program and job
list with ShopMill programs)
● Complete tool list
Tool data for ShopMill programs
-- only available for job list with Shop‐
Mill and G code programs
● No
● All used in the program
● Complete tool list
Tool data for G code programs
-- only available for job list with Shop‐
Mill and G code programs
● No
● Complete tool list
Magazine assignment
● Yes
● No
Zero points
● No
The selection box "Basis reference" is hidden
● All used in the program (only for ShopMill program and job
list with ShopMill programs)
● All
