12.1 Activate collision avoidance
Precondition
● Collision avoidance is setup and an active machine model is available.
● The setting "Collision avoidance" has been selected for the AUTO operating mode or for
the JOG and MDA operating modes.
Procedure
1. Select the "Machine" operating area.
2. Press the <AUTO> key.
3. Press the "Sim. rec." softkey.
4. Press the "Other views" and "Machine space" softkeys.
During simultaneous recording, an active machine model is displayed.
Collision avoidance
12.1 Activate collision avoidance
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 681
