Group Meaning
G group 7 Tool radius compensation (e.g. G40, G42)
G group 8 Settable work offset (e.g. G54, G57, G500)
G group 9 Offset suppression (e.g. SUPA, G53)
G group 10 Exact stop - continuous-path mode (e.g. G60, G641)
G group 13 Workpiece dimensioning inches/metric (e.g. G70, G700)
G group 14 Workpiece dimensioning absolute/incremental (G90)
G group 15 Feedrate type (e.g. G93, G961, G972)
G group 16 Feedrate override on inside and outside curvature (e.g. CFC)
G group 21 Acceleration profile (e.g. SOFT, DRIVE)
G group 22 Tool offset types (e.g. CUT2D, CUT2DF)
G group 29 Radius/diameter programming (e.g. DIAMOF, DIAMCYCOF)
G group 30 Compressor ON/OFF (e.g. COMPOF)
Procedure
1. Select the "Machine" operating area.
...
2. Press the <JOG>, <MDA> or <AUTO> key.
3. Press the "G functions" softkey.
The "G Functions" window is opened.
4. Press the "G functions" softkey again to hide the window.
The G groups selection displayed in the "G Functions" window may differ.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
References
For more information about configuring the displayed G groups, refer to the following document:
SINUMERIK Operate Commissioning Manual
Machining the workpiece
6.13 Displaying G Functions and Auxiliary Functions
Milling
250 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
