Procedure
1. Press the "Details" softkey.
2. Press the "Cut" softkey.
The workpiece is displayed in the cut state.
…
3. Press the corresponding softkey to shift the cutting plane in the required
direction.
Simulating machining
7.8 Changing and adapting a simulation graphic
Milling
292 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
