G code program parameters ShopMill program parameters
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting
rate
Note:
Please observe the information
provided by your machine manu‐
facturer.
rpm
m/min
Parameter Description Unit
Machining posi‐
tion (only for G
code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Centering
● Diameter (centered with reference to the diameter)
The angle for the center drill entered in the tool list is applied.
● Tip (centered with reference to the depth)
The drill is inserted into the workpiece until the programmed insertion depth is
reached.
∅ It is inserted into the workpiece until the diameter is correct. - (for diameter centering only) mm
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1. - (for tip centering only)
mm
DT
● Dwell time (at final drilling depth) in seconds
● Dwell time (at final drilling depth) in revolutions
s
rev
Predrilling
● Yes
● No
ZA Predrilling depth (abs) or predrilling depth referred to the reference point (inc) - ("yes",
only for predrilling)
mm
FA Predrilling feedrate - ("yes", only for predrilling) %
F7min
F/U
Programming technological functions (cycles)
10.1 Drilling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 373
