Parameters in the "Input complete" mode
G code program parameters ShopMill program parameters
Input
● complete
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting
rate
rpm
m/min
Parameter Description Unit
Machining posi‐
tion (only for G
code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Drilling depth
● Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
● Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value programmed
for Z1.
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
Predrilling
● Yes
● No
ZA - (only for pre‐
drilling "yes")
Predrilling depth (abs) or predrilling depth in relation to the reference point (inc) mm
FA - (only for pre‐
drilling "yes")
Reduced predrilling feedrate as a percentage of the drilling feedrate mm/min
%
Predrilling feedrate (ShopMill) mm/min or
mm/rev.
Predrilling feedrate (G code) Distance/
min or dis‐
tance/rev
Through drilling
● Yes
Through drilling with feedrate FD
● No
ZD - (only for
through drilling
"yes")
Depth for feedrate reduction (abs) or depth for feedrate reduction in relation to Z1 (inc) mm
Programming technological functions (cycles)
10.1 Drilling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 375
