Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Thread" and "Drill and thread mill" softkeys.
The "Drilling and thread milling" input window opens.
Parameters, G code program Parameters, ShopMill program
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting
rate
rpm
m/min
Parameter Description Unit
Machining posi‐
tion (only for G
code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
F1
(only for G-code)
Drilling feedrate mm/min
mm/rev
Z0 (only for G
code)
Reference point Z mm
Z1 Thread length (inc) or end point of the thread (abs) mm
D Maximum depth infeed
● D ≥ Z1: Infeed to the final drilling depth
● D < Z1: Several infeeds with stock removal
mm
DF
● Percentage for each additional infeed
DF=100: Infeed increment remains constant
DF<100: Amount of infeed is reduced in direction of final drilling depth Z1
Example: last infeed 4 mm; DF 80%
next infeed = 4 x 80% = 3.2 mm
next but one infeed = 3.2 x 80% = 2.56 mm etc.
● Amount for each additional infeed
%
mm
Programming technological functions (cycles)
10.1 Drilling
Milling
404 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
