6. Steps 4 and 5 are repeated until the programmed spigot depth is reached.
7. The tool moves back to the safety clearance in rapid traverse.
Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Contour milling" and "Spigot" softkeys.
The "Mill spigot" input window opens.
3. Select the "Roughing" machining type.
Parameters in the "Input complete" mode
Parameters, G code program Parameters, ShopMill program
Input
● complete
PRG Name of the program to be generated T Tool name
PL Machining plane D Cutting edge number
Milling direction
● Climbing
cutting
● Conventional
cutting
F Feedrate mm/min
mm/tooth
RP Retraction plane mm S / V Spindle speed or constant cutting
rate
rpm
m/min
SC Safety clearance mm
F Feedrate mm/min
Parameter Description Unit
Machining The following machining operations can be selected:
● ∇ (roughing)
● ∇∇∇ base (base finishing)
● ∇∇∇ edge (edge finishing)
● Chamfering
Z0 Reference point in the tool axis Z mm
Z1 Pocket depth (abs) or depth relative to Z0 (inc)
- (only for ∇, ∇∇∇ base or ∇∇∇ edge)
mm
DXY
● Maximum plane infeed
● Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇ base)
mm
%
DZ Maximum depth infeed – (only for ∇ or ∇∇∇ edge) mm
Programming technological functions (cycles)
10.3 Contour milling
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 509
