3. Press the "Groove" softkey.
The "Groove" input window opens.
4. Select one of the three groove cycles with the softkey:
Simple groove cycle
The "Groove 1" input window opens.
- OR -
Groove cycle with inclines, radii, or chamfers.
The "Groove 2" input window opens.
- OR -
Groove cycle on an incline with inclines, radii or chamfers.
The "Groove 3" input window opens.
G code program parameters ShopMill program parameters
PL Machining plane T
SC Safety clearance mm D Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant cutting rate rpm
m/min
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
