Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter Description Value Can be set in SD
PL Machining plane Defined in MD
52005
G Change in thread pitch per revolution – (only for P = mm/rev
or in/rev):
Without change in thread pitch
0
VR Return distance 2 mm x
Multiple threads 1 Thread No
α0 Starting angle offset 0°
Machine manufacturer
Please observe the information provided by the machine manufacturer.
Parameters in the "complete" mode (tapered thread)
G code program parameters ShopMill program parameters
Input
● complete
PL Machining plane T Tool name
D Cutting edge number
S / V Spindle speed or
Constant cutting rate
rpm
m/min
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 553
