Alternating cutting depth
Instead of working with constant cutting depth D, you can use an alternating cutting depth to
vary the load on the tool edge. As a consequence you can increase the tool life.
VWFXW
QGFXW''
''
Figure 10-12 Alternating cutting depth
The percentage for the alternating cutting depth is saved in a machine data element.
Machine manufacturer
Please observe the information provided by the machine manufacturer.
Cut segmentation
To avoid the occurrence of very thin cuts in cut segmentation due to contour edges, you can
align the cut segmentation to the contour edges. During machining the contour is then divided
by the edges into individual sections and cut segmentation is performed separately for each
section.
Set machining area limits
If, for example, you want to machine a certain area of the contour with a different tool, you can
set machining area limits so that machining only takes place in the area of the contour you
have selected. You can define between 1 and 4 limit lines.
The limit lines must not intersect the contour on the side facing the machining.
This limit has the same effect during roughing and finishing.
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
588 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
