Parameter Description Unit
XD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension ∅ (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
ZD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
● Yes
U1 contour allowance
● No
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is kept
● Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Relief cuts
● Yes (cannot be changed)
FR Insertion feedrate, relief cuts *
* Unit of feedrate as programmed before the cycle call
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter Description Value Can be set in SD
Residual material With subsequent residual material removal No
SC Safety clearance x
PL Machining plane Defined in MD
52005
Selection Always round on the contour
Uniform cut segmentation
Constant cutting depth
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
598 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
