Parameter Description Unit
TC Name of the swivel data set
Note: The selection box only appears if more than one swivel data set has been set up.
Retraction
(for ShopMill pro‐
gram)
● No
The axis is not retracted before swiveling.
● Z
Retraction in the direction of machine axis Z.
● Z,X,Y
Move machining axes to retraction position before swiveling.
● Tool direction, max.
Maximum retraction (up to the software end position) in the tool direction.
● Tool direction, inc.
Incremental retraction (specified retraction distance, up to the software end position)
in the tool direction.
When retracting in the tool direction, in the swiveled machine state, several axes can
move (traverse).
ZR
(for ShopMill pro‐
gram)
Retraction path - only for incremental retraction in mm
Align tool through beta and gamma angles
β
(for ShopMill pro‐
gram)
Align tool with swivel axes
● Input value
The required angle can be freely entered.
● β = 0°
● β = 90°
Degrees
γ
(for ShopMill pro‐
gram)
● 0°
● 180°
● The required angle can be freely entered
Degrees
Directly position rotary axes
B1
(for ShopMill pro‐
gram)
Directly align the tool with the swiveling axes:
The required angle can be freely entered.
Degrees
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 601
