Parameter Description Unit
XDB Second grooving limit tool ∅ (abs) – (end face or rear face only) mm
Allowance Allowance for prefinishing
● Yes
U1 contour allowance
● No
DI For zero: Continuous cut - (only for ∇) mm
XD - (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Allowance or cylinder dimension ∅ (abs)
– Allowance or cylinder dimension (inc)
● For blank description, allowance
– Allowance on the contour ∅ (abs)
– Allowance on the contour (inc)
mm
ZD - (only for blank description, cylinder and allowance)
● For blank description, cylinder
Allowance or cylinder dimension (abs or inc)
● For blank description, allowance
Allowance on the contour (abs or inc)
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is retained
● Negative value: Compensation allowance is removed in addition to finishing allowance
mm
Set machining
area limits
Set machining area limits
● Yes
● No
XA
XB
ZA
ZB
With limited machining area only, yes:
1st limit XA ∅
2nd limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1st limit ZA
2nd limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves (inc) mm
* Unit of feedrate as programmed before the cycle call
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
630 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
