Switching between single- and multi-channel view
Press the <MACHINE> key in order to briefly switch between the single-
and multi-channel view in the machine area.
Press the <NEXT WINDOW> key in order to switch between the upper
and lower window within a channel column.
Editing a program in the block display
You can perform simple editing operations as usual with the <INSERT>
key in the actual block display.
If there is not sufficient space, you switch over into the single-channel view.
Running-in a program
You select individual channels to run-in the program at the machine.
Requirement
● Several channels have been set-up.
● The setting "2 channels", "3 channels" or "4 channels" is selected.
Displaying/hiding a multi-channel view
1. Select the "Machine" operating area
...
2. Select the "JOG", "MDA" or "AUTO" mode.
3. Press the menu forward key and the "Settings" softkey.
4. Press the "Multi-channel view" softkey.
Multi-channel view
11.2 Multi-channel view in the "Machine" operating area
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 673
