- OR -
Press the "Skip" softkey if already existing tools are not to be overwritten.
For an already existing tool, you receive a query.
Selecting loading point
For a magazine, if more than one loading point was set-up, using the "Select loading point"
softkey, you have the option of opening a window in which you can assign a loading point to
a magazine.
Procedure
1. Select the "Program Manager" operating area.
2. Position the cursor on the file with the backed-up tool and zero point data
(*.INI) that you wish to re-import.
3. Press the <Cursor right> key
- OR -
Double-click the file.
The "Read-in setup data" window opens.
4. Select the data (e.g. magazine assignment) that you wish to read-in.
5. Press the "OK" softkey.
Managing programs
14.17 Setup data
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 797
