5. Press the "User enable" softkey.
The "User Agreement" window opens.
It shows a list of all machine axes with their current position and SI
position.
6. Position the cursor in the "Acknowledgement" field for the axis in ques‐
tion.
7. Activate the acknowledgement with the <SELECT> key.
The selected axis is marked with an "x" meaning "safely referenced" in
the "Acknowledgement" column.
By pressing the <SELECT> key again, you deactivate the acknowl‐
edgement again.
Setting up the machine
4.2 Approaching a reference point
Milling
92 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0

Siemens SINUMERIK Series Specifications

General

Axes Control	Up to 31 axes
Category	Control Unit
Manufacturer	Siemens
Series	SINUMERIK
Control Type	CNC
Communication Interfaces	Ethernet, USB
Operating Temperature	0°C to 45°C
Protection Class	IP20
Power Supply	24V DC
Display	Color TFT LCD
