Siemens SIPROTEC 5 Series User Manual

Safety Notes
!
DANGER
Danger during electrical inspection
Noncompliance with the safety notes will result in death, severe injury or considerable material
damage.
²
Comply with all given safety notes when carrying out the electrical inspection.
²
Please note that hazardous voltages are present when you perform the electrical inspection.
²
During the electrical inspection, check that the device becomes ready for operation once it has been
connected to the power supply.
Performing the Electrical Inspection
²
Connect the power supply.
²
Activate the power supply.
After (initial) activation, there is no Device Configuration File (CFG) in the device and the device is in fall-
back mode. The green and red LEDs light up in fallback mode.
²
Once you have loaded the CFG file into the SIPROTEC 5 device, the green RUN LED lights up continuously
and the device is ready for operation.
²
If the device does not assume the normal operating state (process mode), switch off the power supply.
Disconnect the wiring and the grounding.
²
Pack this device and return it to the manufacturer, stating the defect. Use transport packaging that meets
the requirements of standard ISO 2248.
Working on the Device
5.1 First Steps
SIPROTEC 5, Hardware Description, Manual 155
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
