Terminal Designations
The current terminals have different designations in DIGSI, the configurator, and the device. The following
table provides an overview of the different terminal designations and order numbers of the terminals.
Terminal Configurator DIGSI Display on the
Device
Terminal Labeling Ordering No.
(Short Desig-
nation)
Modular Device 50/60 Hz
4 protection-class
current transformers
TypeA-Curr.term.,
4x prot.tion
Current
4x protection
TBC4PROTA C73334A 1A18 *7*
P1Z512
2
3 protection-class
current transformers
and 1 instrument
transformer
TypeA-Curr.term.,
3xprot. 1xsens.
Current 3x
prot., 1x sensi-
tive
TBC3PROTA1M C73334A 1A18 *8*
P1Z529
2
4 instrument trans-
formers
TypeA-Curr.term.,
4x measurem
Current
4x sensitive
TBC4M C73334A 1A18 *9*
P1Z536
2
Modular Device 50/60/16.7 Hz
4 protection-class
current transformers
TypeA-Curr.term.,
4x prot.
Current
4x protection
TBC4PROTA C73334A 1A17 *7* P1Z512
3 protection-class
current transformers
and 1 instrument
transformer
TypeA-Curr.term.,
3xprot. 1xsens.
Current 3x
prot., 1x sensi-
tive
TBC3PROTA1M C73334A 1A17 *8* P1Z529
4 instrument trans-
formers
TypeA-Curr.term.,
4x measurem
Current
4x sensitive
TBC4M C73334A 1A17 *9* P1Z536
Non-Modular Device
4 protection-class
current transformers
TypeB-Curr.term.,
4x prot.
Current
4x protection
TBC4PROTB C73334A 1A18 *5* P1Z1869
3 protection-class
current transformers
and 1 instrument
transformer
TypeB-Curr.term.,
3xprot. 1xsens.
Current 3x
prot., 1x sensi-
tive
TBC3PROTB1M C73334A 1A18 *6* P1Z1647
Connections of Current Terminals
Fasteners
The fasteners for the transformer connection are part of the current terminal (housing side). They are made of
a stress-crack and corrosion-free alloy. The head shape of the clamping screw allows the use of a DIN 5.5 x 1.0
screwdriver or a PZ2 screwdriver. Siemens recommends a PZ2 screwdriver.
Connection Elements and Conductor Cross-Sections
The following connection types are possible:
•
Stranded-wire conductor with ring-type lug
•
Stranded-wire conductor with bootlace ferrule
•
Solid conductor
Siemens recommends the use of ring-type lugs with the dimensions shown in the following figure. Use copper
cables only.
5.7.2
2
The equivalent 50/60/16.7-Hz terminal is used as a re-orderable single part.
Working on the Device
5.7 Installing Current and Voltage Terminals
SIPROTEC 5, Hardware Description, Manual 185
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
