Ethernet COM Link
The Ethernet connection to the CB202 PCB assembly (plug-in module assembly with integrated power supply)
is realized using the RJ45 interface.
The RJ45 interface can be used exclusively for the connection of the CB202 module. This terminal is left
unused when no CB202 module is in use.
For further information on the Ethernet COM link, see chapter 6.6 Communication Interfaces in the Technical
Data.
Power-Supply Module PS203
Description
If you expand the device into the 2nd device row, you need the PS203 power-supply module.
i
i
NOTE
The PS203 power-supply module is always supplied with the expansion module and must always be
mounted at position 7.
Up to 5 additional expansion modules are possible in the 2nd device row. The scope of delivery of the PS203
power-supply module includes 1 connecting cable for the 2nd device row, 1 angle rail, 1 sealing panel and 1
adaptor bracket.
The PS203 power-supply module has no additional functionality. It is used exclusively to supply power to the
2nd device row.
The rated voltage variant of the PS203 power-supply module must always match the PS201 power-supply
module of the base module.
3.1.3
3.1.3.1
Electronic Modules
3.1 Power-Supply Modules of the Modular Devices
48 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
