(3) Sealing plate
(4) Device bus of the outermost left expansion module of the 1st device row
Installation and Commissioning
²
Reinstall the plastic screw covers.
²
Refasten the terminal blocks and the necessary communication lines.
²
Connect the current and voltage blocks of the expansion module.
²
Connect any available plug-in modules.
²
Use the supplied grounding cable to connect the expansion module with the device and reconnect the
device to service ground.
²
Extend the device configuration in DIGSI and load it to the device.
²
Resume operation of the device.
Surface-Mounted Devices with Detached On-Site Operation Panel
Basic Rules for Expansion
i
i
NOTE
Prepare the following tools for the device expansion:
Phillips screwdriver size PZ1 and PZ2
Screwdriver DIN 4 x 0.8
During assembly, use the prescribed torques (see chapter 6.13 Design Data).
Comply with the following basic rules when expanding devices:
Always fit the base module on the right in the 1st device row.
Always fit the expansion modules from right to left.
Always fit the on-site operation panel of the base module on the left.
Always fit the on-site operation panels of the expansion modules from left to right.
Always install a power-supply module PS203 on the right as the first unit in the 2nd device row.
Note that the PS203 must always have the same rated voltage as the base module.
The distance between the device and the on-site operation panel is limited to not more than 5 m (196.85
in) by the length of the connecting cable.
5.2.3
5.2.3.1
Working on the Device
5.2 Expanding Modular Devices
SIPROTEC 5, Hardware Description, Manual 165
C53000-G5040-C002-C, Edition 10.2017
