Mechanical Tests
Vibration and Shock Stress in Stationary Use
Standards IEC 60255-21 and IEC 60068
Vibration Test (sinusoidal)
IEC 60255-21-1, class 2
9
and
IEC 60068-2-6
Sinusoidal 10 Hz to 60 Hz: ± 0.075 mm amplitude
60 Hz to 150 Hz; 10 m/s
2
acceleration
Frequency sweep 1 octave/min
20 cycles in 3 axes perpendicular to one another
Shock Test
IEC 60255-21-2, class 1
Semi-sinusoidal
Acceleration 50 m/s
2
Duration 11 ms
3 shocks each in both directions of the 3 axes
Seismic Tests
IEC 60255-21-3, class 2 and
IEC 60068-3-3
Sinusoidal 3 Hz
10
to 35 Hz:
Frequency sweep 1 octave/min
1 cycle in 3 axes perpendicular to one another
3 Hz to 8 Hz: ± 7.5 mm amplitude (horizontal axes)
3 Hz to 8 Hz: ± 3.5 mm amplitude (vertical axis)
8 Hz to 35 Hz: 20 m/s
2
acceleration (horizontal axes)
8 Hz to 35 Hz: 10 m/s
2
acceleration (vertical axis)
Vibration and Shock Stress During Transport
Standards
IEC 60255-21 and IEC 60068
Vibration Test (sinusoidal)
IEC 60255-21-1, class 2
11
and
IEC 60068-2-6
Sinusoidal 5 Hz to 8 Hz: ± 7.5 mm amplitude
8 Hz to 150 Hz: 20 m/s
2
acceleration
Frequency sweep 1 octave/min
20 cycles in 3 axes perpendicular to one another
Shock Test
IEC 60255-21-2, class 1 and
IEC 60068-2-27
Semi-sinusoidal
Acceleration 150 m/s
2
Duration 11 ms
3 shocks each in both directions of the 3 axes
Continuous shock
IEC 60255-21-2, class 1 and
IEC 60068-2-27
Semi-sinusoidal
Acceleration 100 m/s
2
Duration 16 ms
1000 shocks each in both directions of the 3 axes
6.8
9
The non-modular devices in the assembly frame meet class 1.
10
For technical reasons, the frequency range is raised from 1 Hz to 3 Hz at the lower limit.
11
The non-modular devices in the assembly frame meet class 1.
Technical Data
6.8 Mechanical Tests
SIPROTEC 5, Hardware Description, Manual 205
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
