Siemens SIPROTEC 5 Series User Manual

Standard for Withstand Capability
or Relay Systems to Radiated Elec-
tromagnetic Interference from
Transceivers (Keying test)
IEEE Std C37.90.2
20 V/m
80 MHz to 1 GHz
Pulse modulation
Ring wave immunity test
IEC 61000-4-12
100 kHz (2.5 kV peak value)
Common-mode and differential-mode test
Test duration ≥ 60 s, both polarities
Damped oscillatory wave immunity
test
IEC 61000-4-18
100 kHz, 1 MHz, 2.5 kV (peak value)
3 MHz, 10 MHz, 30 MHz, 2 kV (peak value)
Test duration ≥ 60 s
Power-frequency disturbance test
IEC 61000-4-16
Zone A
150 V (differential mode)
300 V (common mode)
EMC Electromagnetic Emission Tests (Type Tests, Test under Mounting Conditions)
Standards IEC 60255-26 (product standard)
IEC 61000-6-4 (generic standard)
Conducted emission on auxiliary-voltage lines
CISPR 22
150 kHz to 30 MHz limit class A
Radiated emission CISPR 11 30 MHz to 1 000 MHz limit class A
CISPR 22 1 GHz to 6 GHz limit class A
Loading effect in electricity-supply systems, harmonics
Harmonic current emissions
Does not apply!
(see EN 61000-3-2, section 7,
power consumption < 75 W)
Loading effect in electricity-supply systems, voltage fluctuations
Flicker
Does not apply!
(see EN 61000-3-3, section 6, no
significant voltage fluctuations)
Technical Data
6.7 Electrical Tests
204 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
