Terminals
Overview of Terminals
[dwio206p-030211-01.tif, 2, --_--]
Figure 3-28
IO206 – Terminals
(1) Voltage terminal xA
(2) Voltage terminal xD
(3) Protective grounding terminal
i
i
NOTE
x corresponds to the slot in the 19-inch rack.
3.2.7.2
Electronic Modules
3.2 Input and Output Modules of the Modular Devices
