Expanding 1st Device Row
Preparation
i
i
NOTE
Reordered modules are not contained in the original device configuration. Use DIGSI to perform the corre-
sponding extension in the Hardware and Protocols Editor.
Carry out the steps described in this chapter if you wish to expand an installed device later on with expan-
sion modules.
²
Shut down the device.
²
Use the screwdriver to carefully bend the left and right spring clips on the rear plate terminals outwards.
²
Completely detach the wired current and voltage terminal blocks from the device.
²
Remove all communication lines.
²
Remove the plastic screw covers.
²
Remove the device.
²
Expand the cut-out in the control cabinet.
²
Then continue with assembly.
Assembling the Devices
²
Remove the bus cover from the extreme right-hand module of the device to be expanded.
²
Remove the plastic screw covers from the expansion module.
²
Remove the right sealing strips from the base device.
²
Place the expansion module on the right next to the device. Insert the 2 hinged angle clips of the expan-
sion module in the cut-outs of the device.
²
Slip ring the expansion module in the direction of the device so that the bottom snap-in spring engages.
²
Bolt the 2 on-site operation panels of the module to one another through the contact tab.
²
Check that the bus connection is screwed on at the extreme right of the expansion module.
Installation and Commissioning
²
Reinstall the device.
²
Reinstall the plastic screw covers.
²
Refasten the terminal blocks and the necessary communication lines.
²
Connect the current and voltage blocks of the expansion module.
²
Connect any available plug-in modules.
²
Use the supplied grounding cable to connect the expansion module with the device and reconnect the
device to service ground.
²
Extend the device configuration in DIGSI and load this configuration to the device.
²
Resume operation of the device.
5.2.1.2
Working on the Device
5.2 Expanding Modular Devices
SIPROTEC 5, Hardware Description, Manual 157
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
