Siemens SIPROTEC 5 Series User Manual

Ordering Spare Parts and Accessories
Order Configurator and Order Options
Order Configurator
The order configurator assists you in the selection of SIPROTEC 5 products. The order configurator is a Web
application that can be used with any browser. The order configurator can be used to configure complete
devices or individual components, such as communication modules, expansion modules, or other accessories.
At the end of the configuration process, the product code and a detailed presentation of the configuration
result are provided. The product code unambiguously describes the selected product and also serves as an
order number.
Ordering Options
The following ordering options are possible for SIPROTEC 5 products:
•
Device
•
Single part
•
DIGSI 5
•
Functional enhancement
i
i
NOTE
To order single parts in the order configurator, use the Single part link.
Individual parts are:
•
Expansion module
•
Plug-in module
•
Sensors for arc protection
•
Operation panel
•
Terminal
•
Accessories
Ordering Accessories
i
i
NOTE
To order terminals, terminal accessories, and mechanical accessories in the order configurator, use the
Single part link.
Table 7-1 Accessories
Group Accessories
Terminal Voltage terminal, terminal block, 14-pole
Terminal Voltage input (power supply)
Terminal block, 2-pole
18
Terminal Type A current terminal, 4 x protection
(for modular devices)
7.1
7.1.1
7.1.2
18
Recommended tightening torque for fixing the terminal at the rear side: 0.3 Nm
Ordering Information
7.1 Ordering Spare Parts and Accessories
244 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
