Siemens SIPROTEC 5 Series User Manual

Group Accessories
Terminal Type A current terminal, 3 x protection and 1 x measurement
(for modular devices)
Terminal Type A current terminal, 4 x measurement
(for modular devices)
Terminal Type B current terminal, 4 x protection
(for non-modular devices)
Terminal Type B current terminal, 3 x protection and 1 x measurement
(for non-modular devices)
Terminal 2-pole cross connector for current terminal
Terminal
Terminal pair printed circuit board assembly IO110
18
Terminal
Terminals and shielding for IO111
19
,
20
Terminal
Terminal kit for IO230/231
18
Terminal 2-pole cross connector for voltage terminal
Terminal Cover for current terminal block
Terminal Cover for voltage terminal block
Terminal Cover for empty plug-in module positions
Terminal Transport safety, current terminal
Terminal Transport safety, voltage terminal
Accessories USB covers (10 pieces each for CP 100, 200, 300)
Accessories Cable, integrated operation panel, 0.43 m
Accessories Cable, detached operation panel, 2.50 m
Accessories Cable, detached operation panel, 5.00 m
Accessories Cable set, COM link cable
Accessories Cover plate for plug-in modules
Accessories Set of angle rails
Accessories 10 x labeling strip, LEDs/function keys
Accessories 5 x labeling strips, push-buttons
Accessories Set of parts, mounting bracket 1/2
Accessories Set of parts, mounting bracket 2/3
Accessories Set of parts, mounting bracket 5/6
Accessories Set of parts, mounting bracket 1/1
Accessories 4 x screw cover 1/3, type C11
Accessories 4 x screw cover 1/3, type C22
Accessories 4 x screw cover 1/6, type C21
Accessories 2 x bus termination plate
Accessories Assembly frame for panel surface mounting for non-modular
7xx82 devices
Accessories SDHC memory card for 7KE85
Accessories 10 x battery holder
Accessories Connecting cable for 2nd row
Accessories DIGSI 5 USB cable 2.0
Sensors for arc protection Point sensor with line length of 3 m
Sensors for arc protection Point sensor with line length of 4 m
Sensors for arc protection Point sensor with line length of 5 m
Sensors for arc protection Point sensor with line length of 10 m
19
The set consists of terminals and shielding for the IO111 for the terminal positions of M and N.
20
Only for non-modular devices 7xx82
Ordering Information
7.1 Ordering Spare Parts and Accessories
SIPROTEC 5, Hardware Description, Manual 245
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
