Power-Supply Modules of the Modular Devices
Application Sheet of the Power-Supply Modules of the Modular Devices
Module Designation Function Description
PS201
Power-supply module
24 V DC/48 V DC or
DC 60 V to DC 250 V and AC 100 V to AC 230 V
In the base module 1/3 of 19 in
Assembled with 3 binary inputs, 2 binary outputs, and one status life contact
PS203
Power-supply module for supplying the 2nd device row
24 V DC/48 V DC or
DC 60 V to DC 250 V and AC 100 V to AC 230 V
In the expansion module, 1/6 of 19 in
CB202
Plug-in module assembly with internal power supply
24 V DC/48 V DC or
DC 60 V to DC 250 V and AC 100 V to AC 230 V
In the expansion module, 1/6 of 19 in
Power-Supply Module PS201
Description
The power-supply module PS201 is always permanently installed in the base module. The central task is to
supply power to all modules. The following can be found on the PS201 module:
2 positions for plug-in modules (communication modules, measuring-transducer modules)
Terminals for time synchronization, the on-site operation panel, an integrated Ethernet interface, and a
COM link interface
A 14-pole voltage terminal (3 binary inputs and 3 binary outputs)
Battery for the CPU.
The power supply of the other modules is established automatically through the plug-in bus connection when
they are assembled.
The following 2 variants are available for the rated voltage range:
DC 24 V to 48 V
DC 60 V to DC 250 V and AC 100 V to AC 230 V (50 Hz and 60 Hz)
3.1
3.1.1
3.1.2
3.1.2.1
Electronic Modules
3.1 Power-Supply Modules of the Modular Devices
44 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017
