CAUTION
Exercise caution with laser beams of the optical plug-in modules.
Noncompliance with the safety notes can result in medium-severe or slight injuries.
²
Do not look directly into the optical fiber terminals of the active optical plug-in modules, not even with
optical devices. The laser beams can damage the eyes.
²
De-energize the device.
i
i
NOTE
When using optical communication modules, Laser class 1 is maintained in compliance with EN 60825-1
and EN 60825-2 when using optical fibers ≤ 62.5 μm/125 μm.
When using the ARC-CD-3FO module, Laser class 1 is maintained in compliance with EN 60825-1 and
EN 60825-2 when using 1 mm plastic optical fibers.
²
In the case of a surface-mounted device with integrated on-site operation panel, remove the entire on-
site operation panel.
²
Undo the fastening screw and remove the cover plate from the plug-in module position.
Installing the Plug-In Module
²
Push in the plug-in module on the inner guide as far as it will go.
²
Ensure that the EMC contact spring is seated correctly.
²
Bolt down the plug-in module on the assembly frame to a torque of 0.4 Nm.
²
Connect the lines to the terminals.
²
Then check for secure attachment of the plugs.
²
If necessary, fit the on-site operation panel again.
Completing Installation
²
Resume operation of the device.
Removing
Accessories
i
i
NOTE
Seal an unused plug-in module position with a cover plate.
²
Order the module cover plate set of parts to cover the unused plug-in module position.
5.3.3
Working on the Device
5.3 Plug-In Modules
SIPROTEC 5, Hardware Description, Manual 169
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Series Specifications

General

Protection Functions	Overcurrent, differential, distance, over/under voltage, frequency
Communication Protocols	IEC 61850, IEC 60870-5-103, Modbus, DNP3, PROFINET
Display	Graphical LCD with touch functionality
Inputs/Outputs	Digital and analog inputs/outputs, configurable
Power Supply	24-250V DC or 100-240V AC
Mounting	Panel or rack mounting
Environmental Conditions	Operating temperature: -25°C to +70°C, humidity up to 95% non-condensing
Product Type	Multifunctional protection relay
Application	Power generation, transmission, distribution, industrial plants
Cybersecurity	IEC 62351, role-based access control, secure communication
Modular Design	Yes, with plug-in modules for flexibility
Hardware	Robust design with high processing power
Software	SIPROTEC 5 DIGSI software for configuration and operation
Control Functions	Remote control, switching sequences, interlocking
Monitoring Functions	Event recording, disturbance recording, measurement values
HMI	Integrated HMI with graphical display and pushbuttons. Remote HMI via web browser or dedicated software. User-configurable dashboards and single-line diagrams.
Time Synchronization	IRIG-B, SNTP, PTP (IEEE 1588)
Certifications	IEC, IEEE, UL, CE
