Siemens SIPROTEC 5 Series

Terminals
Overview of Terminals
[dwio205p-030211-01.tif, 2, --_--]
Figure 3-25
IO205 – Terminals
(1) Voltage terminal xA
(2) Voltage terminal xB
(3) Voltage terminal xC
(4) Voltage terminal xD
(5) Protective grounding terminal
i
i
NOTE
x corresponds to the slot in the 19-inch rack.
3.2.6.2
Electronic Modules
3.2 Input and Output Modules of the Modular Devices
SIPROTEC 5, Hardware Description, Manual 67
C53000-G5040-C002-C, Edition 10.2017
