Page #54 background imageLoading...
Page #54 background image
Input and Output Modules of the Modular Devices
Function Description of the Input and Output Modules of the Modular Devices
Module Designation Function Description
IO201
Input and output module
4 current measuring inputs, 8 binary inputs, 6 binary outputs
IO202
Input and output module
4 current measuring inputs, 4 voltage measuring inputs, 8 binary inputs,
6 binary outputs
IO203
Input and output module
8 current measuring inputs, 4 binary inputs, 4 binary outputs
IO204
Input and output module
10 binary inputs, 4 binary outputs, 4 power relays for controlling 2 motors
IO205
Input and output module
12 binary inputs, 16 binary outputs
IO206
Input and output module
6 binary inputs, 7 binary outputs
IO207
Input and output module
16 binary inputs, 8 binary outputs
IO208
Input and output module
4 current measuring inputs, 4 voltage measuring inputs, 4 binary inputs,
11 binary outputs
IO209
Input and output module
8 binary inputs, 4 high-speed binary outputs (semiconductor accelerated)
IO210
Input and output module
4 current measuring inputs, 3 voltage measuring inputs, 4 high-speed meas-
uring-transducer inputs for current or voltage, 7 binary outputs
IO211
Input and output module
8 voltage inputs, 8 binary inputs
IO212
Input and output module
8 high-speed measuring-transducer inputs for current or voltage, 8 binary
inputs
IO214
Input and output module
4 current measuring inputs, 4 voltage measuring inputs, 2 binary inputs,
5 binary outputs
IO215
Input and output module
4 current measuring inputs, 4 voltage measuring inputs (measuring range:
7.07 V), 8 binary inputs, 6 binary outputs
IO230
Input module
48 binary inputs
IO231
Input and output module
24 binary inputs
24 binary outputs
IO233
Input module with special version for binary inputs. You can find more infor-
mation in chapter 6 Technical Data.
48 binary inputs
PB201
Process-bus module
7 duplex LC interfaces of which 1 is a service port
3.2
3.2.1
Electronic Modules
3.2 Input and Output Modules of the Modular Devices
54 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017
