[dwauzeil-040211-01.tif, 2, --_--]
Figure 2-11
Basic and Expansion Module of the Surface-Mounting Device
(1) Mounting bracket
NOTE
When a base module is expanded, 2 mounting brackets must be fitted between the on-site operation
panels and the distance frame. The mounting bracket stabilizes the device. The length of the mounting
bracket corresponds to the width of the device.
Forms of Devices and On-Site Operation Panels
2.2 Surface-Mounted Devices with Integrated On-Site Operation Panel
SIPROTEC 5, Hardware Description, Manual 29
C53000-G5040-C002-C, Edition 10.2017
