Siemens SIPROTEC 7SD80 User Manual

Functions
2.5 Inrush Restraint
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
100
2.5.3 Settings
2.5.4 Information List
Addr. Parameter Setting Options Default Setting Comments
2301 INRUSH REST. OFF
ON
OFF Inrush Restraint
2302 2nd HARMONIC 10 .. 45 % 15 % 2nd. harmonic in % of fundamen-
tal
2303 CROSS BLOCK NO
YES
NO Cross Block
2305 MAX INRUSH PEAK 1.1 .. 25.0 A 15.0 A Maximum inrush-peak value
2310 CROSSB 2HM 0.00 .. 60.00 sec; ∞ 0.00 sec Time for Crossblock with 2nd har-
monic
No. Information Type of In-
formation
Comments
3102 2nd Harmonic A OUT Tolerance invalid in phase A
3103 2nd Harmonic B OUT Tolerance invalid in phase B
3104 2nd Harmonic C OUT Tolerance invalid in phase C
