Functions
2.1 General
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
47
2.1.6.2 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under "Display Additional Settings".
The table indicates region-specific default settings. Column C (configuration) indicates the corresponding sec-
ondary nominal current of the current transformer.
Addr. Parameter C Setting Options Default Setting Comments
1103 FullScaleVolt. 0.4 .. 500.0 kV 10.0 kV Measurem:FullScaleVolt-
age(Equipm.rating)
1104 FullScaleCurr. 10 .. 20000 A 400 A Measurem:FullScaleCur-
rent(Equipm.rating)
1107 P,Q sign not reversed
reversed
not reversed P,Q operational measured
values sign
1130A PoleOpenCurrent 1A 0.05 .. 1.00 A 0.10 A Pole Open Current
Threshold
5A 0.25 .. 5.00 A 0.50 A
1131A PoleOpenVoltage 2 .. 70 V 30 V Pole Open Voltage
Threshold
1132A SI Time all Cl. 0.01 .. 30.00 sec 0.10 sec Seal-in Time after ALL clo-
sures
1133A T DELAY SOTF 0.05 .. 30.00 sec 0.25 sec minimal time for line open
before SOTF
1134 Line Closure only with ManCl
I OR V or ManCl
52a OR I or M/C
I or Man.Close
only with ManCl Recognition of Line Clo-
sures with
1135 Reset Trip CMD CurrentOpenPole
Current AND 52a
Pickup Reset
CurrentOpenPole RESET of Trip Command
1150A SI Time Man.Cl 0.01 .. 30.00 sec 0.30 sec Seal-in Time after
MANUAL closures
1152 Man.Clos. Imp. (Setting options depend
on configuration)
None MANUAL Closure Impulse
after CONTROL
