Siemens SIPROTEC 7SD80 User Manual

Functions
2.17 Additional Functions
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
205
2.17.3.2 Information List
No. Information Type of In-
formation
Comments
601 Ia = MV Ia
602 Ib = MV Ib
603 Ic = MV Ic
610 3I0 = MV 3I0 (zero sequence)
611 3I0sen= MV 3I0sen (sensitive zero sequence)
612 Ig = MV Ig (grounded transformer)
613 3I0par= MV 3I0par (parallel line neutral)
619 I1 = MV I1 (positive sequence)
620 I2 = MV I2 (negative sequence)
621 Va = MV Va
622 Vb = MV Vb
623 Vc = MV Vc
624 Va-b= MV Va-b
625 Vb-c= MV Vb-c
626 Vc-a= MV Vc-a
627 VN = MV VN
631 3V0 = MV 3V0 (zero sequence)
634 V1 = MV V1 (positive sequence)
635 V2 = MV V2 (negative sequence)
641 P = MV P (active power)
642 Q = MV Q (reactive power)
643 PF = MV Power Factor
644 Freq= MV Frequency
645 S = MV S (apparent power)
684 Vo = MV Vo (zero sequence)
801 Θ/Θtrip = MV Temperat. rise for warning and trip
802 Θ/Θtrip A= MV Temperature rise for phase A
803 Θ/Θtrip B= MV Temperature rise for phase B
804 Θ/Θtrip C= MV Temperature rise for phase C
7731 Φ I AB= MV PHI I AB (local)
7732 Φ I BC= MV PHI I BC (local)
7733 Φ I CA= MV PHI I CA (local)
7734 Φ V AB= MV PHI V AB (local)
7735 Φ V BC= MV PHI V BC (local)
7736 Φ V CA= MV PHI V CA (local)
7737 Φ VI A= MV PHI VI A (local)
7738 Φ VI B= MV PHI VI B (local)
7739 Φ VI C= MV PHI VI C (local)
