Siemens SIPROTEC 7SD80 User Manual

Technical Data
4.1 General Device Data
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
290
4.1.6 Mechanical Stress Tests
Vibration and Shock Stress during Stationary Operation
Vibration and Shock Stress during Transport
4.1.7 Climatic Stress Tests
Temperatures
Standards: IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class II;
IEC 60068-2-6
Sinusoidal
10 Hz to 60 Hz: ± 0.075 mm amplitude; 60 Hz to 150 Hz:
1g acceleration
frequency sweep rate 1 octave/min 20 cycles in 3 orthog-
onal axes.
Shock
IEC 60255-21-2, Class I;
IEC 60068-2-27
Semi-sinusoidal
5 g acceleration, duration 11 ms, each 3 shocks in both
directions of the 3 axes
Seismic Vibration
IEC 60255-21-3, Class II;
IEC 60068-3-3
Sinusoidal
1 Hz to 8 Hz: ±7.5 mm amplitude (horizontal axis)
1 Hz to 8 Hz: ±3.5 mm amplitude (vertical axis)
8 Hz to 35 Hz: 2 g acceleration (horizontal axis)
8 Hz to 35 Hz: 1 g acceleration (vertical axis)
Frequency sweep 1 octave/min
1 cycle in 3 orthogonal axes
Standards: IEC 60255-21 and IEC 60068
Oscillation
IEC 60255-21-1, Class 2;
IEC 60068-2-6
Sinusoidal
5 Hz to 8 Hz: ±7.5 mm amplitude;
8 Hz to 150 Hz: 2 g acceleration
Frequency sweep 1 octave/min
20 cycles in 3 orthogonal axes
Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-27
Semi-sinusoidal
15 g acceleration, duration 11 ms,
each 3 shocks (in both directions of the 3 axes)
Continuous Shock
IEC 60255-21-2, Class 1;
IEC 60068-2-29
Semi-sinusoidal
10 g acceleration, duration 16 ms,
each 1000 shocks (in both directions of the 3 axes)
Standards: IEC 60255-6
Type test (in acc. with IEC 60068-2-1 and -2, Test
Bd for 16 h)
–25 °C to +85 °C or –13 °F to +185 °F
Permissible temporary operating temperature
(tested for 96 h)
–20 °C to +70 °C or –4 °F to +158 °F (clearness of the
display may be impaired from +55 °C or +131 °F)
Recommended for permanent operation (in acc.
with IEC 60255-6)
–5 °C to +55 °C or +23 °F to +131 °F
Limit temperatures for storage –25 °C to +55 °C or –13 °F to +131 °F
Limit temperatures for transport –25 °C to +70 °C or –13 °F to +158 °F
Storage and transport with factory packaging
