2.11 Automatic Reclosure Function 79 (Optional)
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
154
2.11.4 Information List
No. Information Type of In-
formation
Comments
127 79 ON/OFF IntSP 79 ON/OFF (via system port)
2701 >79 ON SP >79 ON
2702 >79 OFF SP >79 OFF
2703 >BLOCK 79 SP >BLOCK 79
2711 >79 Start SP >79 External start of internal A/R
2716 >79 TRIP 3p SP >79: External 3pole trip for AR start
2727 >79 RemoteClose SP >79: Remote Close signal
2738 >BLOCK 3pole AR SP >79: Block 3pole AR-cycle
2739 >BLK 1phase AR SP >79: Block 1phase-fault AR-cycle
2740 >BLK 2phase AR SP >79: Block 2phase-fault AR-cycle
2741 >BLK 3phase AR SP >79: Block 3phase-fault AR-cycle
2742 >BLK 1.AR-cycle SP >79: Block 1st AR-cycle
2743 >BLK 2.AR-cycle SP >79: Block 2nd AR-cycle
2746 >Trip for AR SP >79: External Trip for AR start
2752 >Pickup 3ph AR SP >79: External pickup 3phase for AR start
2781 79 OFF OUT 79: Auto recloser is switched OFF
2782 79 ON IntSP 79: Auto recloser is switched ON
2783 79 is blocked OUT 79: Auto recloser is blocked
2784 79 not ready OUT 79: Auto recloser is not ready
2787 CB not ready OUT 79: Circuit breaker 1 not ready
2788 79 T-CBreadyExp OUT 79: CB ready monitoring window expired
2796 79 on/off BI IntSP 79: Auto recloser ON/OFF via BI
2801 79 in progress OUT 79 - in progress
2809 79 T-Start Exp OUT 79: Start-signal monitoring time expired
2810 79 TdeadMax Exp OUT 79: Maximum dead time expired
2818 79 Evolving Flt OUT 79: Evolving fault recognition
2821 79 Td. evol.Flt OUT 79 dead time after evolving fault
2840 79 Tdead 3pTrip OUT 79 dead time after 3pole trip running
2843 79 Tdead 3pFlt OUT 79 dead time after 3phase fault running
2844 79 1stCyc. run. OUT 79 1st cycle running
2845 79 2ndCyc. run. OUT 79 2nd cycle running
2851 79 Close OUT 79 - Close command
2853 79 Close1.Cyc3p OUT 79: Close command after 3pole, 1st cycle
2854 79 Close 2.Cyc OUT 79: Close command 2nd cycle (and higher)
2861 79 T-Recl. run. OUT 79: Reclaim time is running
2862 79 Successful OUT 79 - cycle successful
2871 79 TRIP 3pole OUT 79: TRIP command 3pole
2889 79 1.CycZoneRel OUT 79 1st cycle zone extension release
2890 79 2.CycZoneRel OUT 79 2nd cycle zone extension release
2894 79 Remote Close OUT 79 Remote close signal send
