Functions
2.1 General
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
51
2.1.8.3 Settings
2.1.8.4 Information List
Addr. Parameter Setting Options Default Setting Comments
4501 PDI FO ON
OFF
ON Protection Data Interface fiber
optic
4502 PDI FO TER 0.5 .. 20.0 % 1.0 % PDI FO max. telegram error rate
4503 PDI FO level -30 .. -10 dBm -28 dBm PDI FO min. receive level
4510 TD-DATA DISTURB 0.05 .. 2.00 sec 0.10 sec Time delay for data disturbance
alarm
4512 Td ResetRemote 0.00 .. 300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY for
comm.fail
4601 PDI Cu ON
OFF
ON Protection Data Interface copper
4602 PDI Cu TER 0.5 .. 20.0 % 1.0 % PDI Cu max. telegram error rate
4603 PDI Cu mode 01
02
03
04
05
06
01 PDI Cu operation mode
4604 PDI Cu MAX ATT 0 .. 46 dB 46 dB PDI Cu maximum attenuation
4605 PDI Cu S/N 6 .. 30 dB 6 dB PDI Cu min signal to noise ratio
No. Information Type of In-
formation
Comments
3217 PDI FO mirror OUT PDI FO data mirror
3218 PDI Cu mirror OUT PDI Cu data mirror
3227 >PDI FO stop SP >PDI FO is stopped
3228 >PDI Cu stop SP >PDI Cu is stopped
3230 PDI FO faulty OUT PDI FO failure
3232 PDI Cu faulty OUT PDI Cu failure
3243 PDI FO con. to. VI PDI FO connected to relay ID
3244 PDI Cu con. to. VI PDI Cu connected to relay ID
3258 PDI FO TER OUT PDI FO telegram error rate exceeded
3259 PDI Cu TER OUT PDI Cu telegram error rate exceeded
32227 PDI-FO RQ LOW OUT PDI-FO receive level to low
32228 PDI-Cu ATT HIGH OUT PDI-FO attenuation to high
32229 PDI-Cu S/N LOW OUT PDI-FO signal to noise ratio to low
