A.5 Default Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
352
A.5.3 Binary Output
Table A-5 Output Relay Presettings for All Devices and Ordering Variants
A.5.4 Function Keys
Table A-6 Applies to All Devices and Ordered Variants
Binary Output Default function Function No. Description
BO1 Emer. mode 2054 Emergency mode
BO2 Alarm Sum Event 160 Alarm Summary Event
BO3 Relay PICKUP 501 Relay PICKUP
BO4 Relay TRIP 511 Relay GENERAL TRIP command
BO5 Relay TRIP 511 Relay GENERAL TRIP command
BO6 Rem.Sig 1 Rx 3573 Remote signal 1 received
BO7 PDI FO faulty 3230 PDI FO failure
PDI Cu faulty 3232 PDI Cu failure
BO8 - - -
Function Keys Default function
F1 Display of operational indications
F2 Display of the primary operational measured values
F3 Overview of the last 8 fault indications
F4 no default value
