A.9 Information List
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
371
A.9 Information List
Indications for IEC 60 870-5-103 are always reported ON / OFF if they are subject to general interrogation for
IEC 60 870-5-103. If not, they are reported only as ON.
New user-defined indications or such newly allocated to IEC 60 870-5-103 are set to ON / OFF and subjected
to general interrogation if the information type is not a spontaneous event („.._Ev“). Further information with
regard to the indications is set out in the SIPROTEC 4 System Description, Order No. E50417-H1100-C151.
In columns „Event Log“, „Trip Log“ and „Ground Fault Log“ the following applies:
UPPER CASE NOTATION “ON/OFF”: definitely set, not allocatable
lower case notation “on/off”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
In the column „Marked in Oscill. Record“ the following applies:
UPPER CASE NOTATION “M”: definitely set, not allocatable
lower case notation “m”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
- Test mode (Test mode) Device, General IntSP On
Off
* * LED BO 192 21 1 Yes
- Stop data transmission (DataS-
top)
Device, General IntSP On
Off
* * LED BO 192 20 1 Yes
- Unlock data transmission via BI
(UnlockDT)
Device, General IntSP *
- Reset LED (Reset LED) Device, General IntSP ON * * LED BO 192 19 1 No
- Clock Synchronization (Synch-
Clock)
Device, General IntSP
_Ev
* * * LED BO
- >Back Light on (>Light on) Device, General SP On
Off
*BI
- Hardware Test Mode (HWTest-
Mod)
Device, General IntSP On
Off
**LEDBO
- Error FMS FO 1 (Error FMS1) Device, General OUT On
Off
** LED BO
- Error FMS FO 2 (Error FMS2) Device, General OUT On
Off
** LED BO
- Disturbance CFC (Distur.CFC) Device, General OUT On
Off
* LED BO
- Breaker OPENED (Brk
OPENED)
Device, General IntSP * * * LED BO
- Feeder GROUNDED (Feeder
gnd)
Device, General IntSP * * * LED BO
- Setting Group A is active (P-GrpA
act)
Change Group IntSP On
Off
* * LED BO 192 23 1 Yes
- Setting Group B is active (P-GrpB
act)
Change Group IntSP On
Off
* * LED BO 192 24 1 Yes
