Siemens SIPROTEC 7SD80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
370
4205 I ALARM 49 Th.Overload 1A 0.10 .. 4.00 A 1.00 A Current Overload Alarm Setpoint
5A 0.50 .. 20.00 A 5.00 A
4206 CALC. METHOD 49 Th.Overload Θ max
Average Θ
Θ from Imax
Θ max Method of Acquiring Tempera-
ture
4501 PDI FO Prot.Interface ON
OFF
ON Protection Data Interface fiber
optic
4502 PDI FO TER Prot.Interface 0.5 .. 20.0 % 1.0 % PDI FO max. telegram error rate
4503 PDI FO level Prot.Interface -30 .. -10 dBm -28 dBm PDI FO min. receive level
4510 TD-DATA DISTURB Prot.Interface 0.05 .. 2.00 sec 0.10 sec Time delay for data disturbance
alarm
4512 Td ResetRemote Prot.Interface 0.00 .. 300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY
for comm.fail
4601 PDI Cu Prot.Interface ON
OFF
ON Protection Data Interface copper
4602 PDI Cu TER Prot.Interface 0.5 .. 20.0 % 1.0 % PDI Cu max. telegram error rate
4603 PDI Cu mode Prot.Interface 01
02
03
04
05
06
01 PDI Cu operation mode
4604 PDI Cu MAX ATT Prot.Interface 0 .. 46 dB 46 dB PDI Cu maximum attenuation
4605 PDI Cu S/N Prot.Interface 6 .. 30 dB 6 dB PDI Cu min signal to noise ratio
4701 ID OF MASTER Diff.-Topo 1 .. 65534 1 Identification number of Master
4702 ID OF SLAVE Diff.-Topo 1 .. 65534 2 Identification number of Slave
4710 LOCAL RELAY Diff.-Topo Master
Slave
Master Local relay is
Addr. Parameter Function C Setting Options Default Setting Comments
