Siemens SIPROTEC 7SD80 User Manual

Appendix
A.11 Measured Values
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
394
A.11 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Control DIGSI (CntrlDIGSI) Cntrl Authority - - - - - CFC CD DD
- I A dmd> (I Admd>) Set Points(MV) - - - - - CFC CD DD
- I B dmd> (I Bdmd>) Set Points(MV) - - - - - CFC CD DD
- I C dmd> (I Cdmd>) Set Points(MV) - - - - - CFC CD DD
- I1dmd> (I1dmd>) Set Points(MV) - - - - - CFC CD DD
- |Pdmd|> (|Pdmd|>) Set Points(MV) - - - - - CFC CD DD
- |Qdmd|> (|Qdmd|>) Set Points(MV) - - - - - CFC CD DD
- |Sdmd|> (|Sdmd|>) Set Points(MV) - - - - - CFC CD DD
- |Power Factor|< (|PF|<) Set Points(MV) - - - - - CFC CD DD
601 Ia (Ia =) Measurement 134 129 No 9 1 CFC CD DD
602 Ib (Ib =) Measurement 134 129 No 9 2 CFC CD DD
603 Ic (Ic =) Measurement 134 129 No 9 3 CFC CD DD
610 3I0 (zero sequence) (3I0 =) Measurement 134 129 No 9 14 CFC CD DD
611 3I0sen (sensitive zero sequence) (3I0sen=) Measurement - - - - - CFC CD DD
612 Ig (grounded transformer) (Ig =) Measurement - - - - - CFC CD DD
613 3I0par (parallel line neutral) (3I0par=) Measurement - - - - - CFC CD DD
619 I1 (positive sequence) (I1 =) Measurement - - - - - CFC CD DD
620 I2 (negative sequence) (I2 =) Measurement - - - - - CFC CD DD
621 Va (Va =) Measurement 134 129 No 9 4 CFC CD DD
622 Vb (Vb =) Measurement 134 129 No 9 5 CFC CD DD
623 Vc (Vc =) Measurement 134 129 No 9 6 CFC CD DD
624 Va-b (Va-b=) Measurement 134 129 No 9 10 CFC CD DD
625 Vb-c (Vb-c=) Measurement 134 129 No 9 11 CFC CD DD
626 Vc-a (Vc-a=) Measurement 134 129 No 9 12 CFC CD DD
627 VN (VN =) Measurement - - - - - CFC CD DD
631 3V0 (zero sequence) (3V0 =) Measurement - - - - - CFC CD DD
634 V1 (positive sequence) (V1 =) Measurement - - - - - CFC CD DD
635 V2 (negative sequence) (V2 =) Measurement - - - - - CFC CD DD
641 P (active power) (P =) Measurement 134 129 No 9 7 CFC CD DD
642 Q (reactive power) (Q =) Measurement 134 129 No 9 8 CFC CD DD
643 Power Factor (PF =) Measurement 134 129 No 9 13 CFC CD DD
644 Frequency (Freq=) Measurement 134 129 No 9 9 CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
684 Vo (zero sequence) (Vo =) Measurement - - - - - CFC CD DD
801 Temperat. rise for warning and trip (Θ/Θtrip
=)
Measurement - - - - - CFC CD DD
802 Temperature rise for phase A (Θ/Θtrip A=) Measurement - - - - - CFC CD DD
803 Temperature rise for phase B (Θ/Θtrip B=) Measurement - - - - - CFC CD DD
804 Temperature rise for phase C (Θ/Θtrip C=) Measurement - - - - - CFC CD DD
833 I1 (positive sequence) Demand (I1 dmd=) Demand meter - - - - - CFC CD DD
834 Active Power Demand (P dmd =) Demand meter - - - - - CFC CD DD
835 Reactive Power Demand (Q dmd =) Demand meter - - - - - CFC CD DD
836 Apparent Power Demand (S dmd =) Demand meter - - - - - CFC CD DD
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CFC CD DD
