Appendix
A.5 Default Settings
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
351
A.5 Default Settings
A.5.1 LEDs
Table A-3 Preset LED displays
A.5.2 Binary Input
Table A-4 Binary input presettings for all devices and ordering variants
LEDs Default function Function No. Description
LED1 Relay TRIP 511 Relay GENERAL TRIP command
LED2 Relay PICKUP ØA 503 Relay PICKUP Phase A
LED3 Relay PICKUP ØB 504 Relay PICKUP Phase B
LED4 Relay PICKUP ØC 505 Relay PICKUP Phase C
LED5 Relay PICKUP G 506 Relay PICKUP GROUND
LED6 87(N)L Gen.TRIP 32125 87(N)L General TRIP
85 DT Gen. TRIP 3517 85 DT: General TRIP
LED7 Emer. mode 2054 Emergency mode
LED8 Alarm Sum Event 160 Alarm Summary Event
Failure Σi 289 Alarm: Current summation supervision
Binary Input Default function Function No. Description
BI1 >85 DT 3pol 3504 >86 DT: >Intertrip 3 pole signal input
BI2 >87L block 32100 >87L Protection blocking signal
>87N L block 32120 >87N L Protection blocking signal
BI3 >BLOCK 50-STUB 7130 >BLOCK 50-STUB
>BLOCK 50N-STUB 7132 >BLOCK 50N-STUB
BI4 >Rem. Signal 1 3549 >Remote Signal 1 input
BI5 >52a 3p Closed 379 >52a Bkr. aux. contact (3pole closed)
>52a Bkr1 3p Cl 410 >52a Bkr1 aux. 3pClosed (for AR,CB-Test)
BI6 >52b 3p Open 380 >52b Bkr. aux. contact (3pole open)
>52b Bkr1 3p Op 411 >52b Bkr1 aux. 3p Open (for AR,CB-Test)
BI7 >Manual Close 356 >Manual close signal
