2.8 Undervoltage and Overvoltage Protection 27/59 (Optional)
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
130
2.8.5 Information List
3773 27-1-V1 DELAY 0.00 .. 100.00 sec; ∞ 2.00 sec 27-1 Time Delay
3774 27-2-V1 PICKUP 1.0 .. 100.0 V; 0 10.0 V 27-2 Pickup Undervoltage (pos.
seq.)
3775 27-2-V1 DELAY 0.00 .. 100.00 sec; ∞ 1.00 sec 27-2 Time Delay
3778 CURR.SUP. 27-V1 ON
OFF
ON Current supervision (V1)
3779A 27-V1 RESET 1.01 .. 1.20 1.05 Reset ratio
No. Information Type of In-
formation
Comments
234.2100 27, 59 blk IntSP 27, 59 blocked via operation
10201 >59-Vphg BLOCK SP >BLOCK 59-Vphg Overvolt. (phase-ground)
10202 >59-Vphph BLOCK SP >BLOCK 59-Vphph Overvolt (phase-phase)
10203 >59-3V0 BLOCK SP >BLOCK 59-3V0 Overvolt. (zero sequence)
10204 >59-V1 BLOCK SP >BLOCK 59-V1 Overvolt. (positive seq.)
10205 >59-V2 BLOCK SP >BLOCK 59-V2 Overvolt. (negative seq.)
10206 >27-Vphg BLOCK SP >BLOCK 27-Vphg Undervolt. (phase-ground)
10207 >27-Vphph BLOCK SP >BLOCK 27-Vphph Undervolt (phase-phase)
10208 >27-V1 BLOCK SP >BLOCK 27-V1 Undervolt (positive seq.)
10215 59-Vphg OFF OUT 59-Vphg Overvolt. is switched OFF
10216 59-Vphg BLK OUT 59-Vphg Overvolt. is BLOCKED
10217 59-Vphph OFF OUT 59-Vphph Overvolt. is switched OFF
10218 59-Vphph BLK OUT 59-Vphph Overvolt. is BLOCKED
10219 59-3V0 OFF OUT 59-3V0 Overvolt. is switched OFF
10220 59-3V0 BLK OUT 59-3V0 Overvolt. is BLOCKED
10221 59-V1 OFF OUT 59-V1 Overvolt. is switched OFF
10222 59-V1 BLK OUT 59-V1 Overvolt. is BLOCKED
10223 59-V2 OFF OUT 59-V2 Overvolt. is switched OFF
10224 59-V2 BLK OUT 59-V2 Overvolt. is BLOCKED
10225 27-Vphg OFF OUT 27-Vphg Undervolt. is switched OFF
10226 27-Vphg BLK OUT 27-Vphg Undervolt. is BLOCKED
10227 27-Vphph OFF OUT 27-Vphph Undervolt. is switched OFF
10228 27-Vphph BLK OUT 27-Vphph Undervolt. is BLOCKED
10229 27-V1 OFF OUT 27-V1 Undervolt. is switched OFF
10230 27-V1 BLK OUT 27-V1 Undervolt. is BLOCKED
10231 27/59 ACTIVE OUT 27/59 Voltage protection is ACTIVE
10240 59-1-Vpg Pickup OUT 59-1-Vphg Pickup
10241 59-2-Vpg Pickup OUT 59-2-Vphg Pickup
10242 59-Vpg PU A OUT 59-Vphg Pickup A
10243 59-Vpg PU B OUT 59-Vphg Pickup B
10244 59-Vpg PU C OUT 59-Vphg Pickup C
10245 59-1-VpgTimeOut OUT 59-1-Vphg TimeOut
10246 59-2-VpgTimeOut OUT 59-2-Vphg TimeOut
