Siemens SIPROTEC 7SD80 User Manual

Functions
2.8 Undervoltage and Overvoltage Protection 27/59 (Optional)
SIPROTEC, 7SD80, Manual
E50417-G1140-C474-A1, Release date 09.2011
131
10247 59-Vpg TRIP OUT 59-Vphg TRIP command
10248 59-1-Vpg PU A OUT 59-1-Vphg Pickup A
10249 59-1-Vpg PU B OUT 59-1-Vphg Pickup B
10250 59-1-Vpg PU C OUT 59-1-Vphg Pickup C
10251 59-2-Vpg PU A OUT 59-2-Vphg Pickup A
10252 59-2-Vpg PU B OUT 59-2-Vphg Pickup B
10253 59-2-Vpg PU C OUT 59-2-Vphg Pickup C
10255 59-1-Vpp Pickup OUT 59-1-Vphph Pickup
10256 59-2-Vpp Pickup OUT 59-2-Vphph Pickup
10257 59-Vpp PickupAB OUT 59-Vphph Pickup A-B
10258 59-Vpp PickupBC OUT 59-Vphph Pickup B-C
10259 59-Vpp PickupCA OUT 59-Vphph Pickup C-A
10260 59-1-VppTimeOut OUT 59-1-Vphph TimeOut
10261 59-2-VppTimeOut OUT 59-2-Vphph TimeOut
10262 59-Vpp TRIP OUT 59-Vphph TRIP command
10263 59-1-Vpp PU AB OUT 59-1-Vphph Pickup A-B
10264 59-1-Vpp PU BC OUT 59-1-Vphph Pickup B-C
10265 59-1-Vpp PU CA OUT 59-1-Vphph Pickup C-A
10266 59-2-Vpp PU AB OUT 59-2-Vphph Pickup A-B
10267 59-2-Vpp PU BC OUT 59-2-Vphph Pickup B-C
10268 59-2-Vpp PU CA OUT 59-2-Vphph Pickup C-A
10270 59-1-3V0 Pickup OUT 59-1-3V0 Pickup
10271 59-2-3V0 Pickup OUT 59-2-3V0 Pickup
10272 59-1-3V0TimeOut OUT 59-1-3V0 TimeOut
10273 59-2-3V0TimeOut OUT 59-2-3V0 TimeOut
10274 59-3V0 TRIP OUT 59-3V0 TRIP command
10280 59-1-V1 Pickup OUT 59-1-V1 Pickup
10281 59-2-V1 Pickup OUT 59-2-V1 Pickup
10282 59-1-V1TimeOut OUT 59-1-V1 TimeOut
10283 59-2-V1TimeOut OUT 59-2-V1 TimeOut
10284 59-V1 TRIP OUT 59-V1 TRIP command
10290 59-1-V2 Pickup OUT 59-1-V2 Pickup
10291 59-2-V2 Pickup OUT 59-2-V2 Pickup
10292 59-1-V2TimeOut OUT 59-1-V2 TimeOut
10293 59-2-V2TimeOut OUT 59-2-V2 TimeOut
10294 59-V2 TRIP OUT 59-V2 TRIP command
10300 27-1-V1 Pickup OUT 27-1-V1 Pickup
10301 27-2-V1 Pickup OUT 27-2-V1 Pickup
10302 27-1-V1TimeOut OUT 27-1-V1TimeOut
10303 27-2-V1TimeOut OUT 27-2-V1TimeOut
10304 27-V1 TRIP OUT 27-V1 TRIP command
10310 27-1-Vpg Pickup OUT 27-1-Vphg Pickup
10311 27-2-Vpg Pickup OUT 27-2-Vphg Pickup
10312 27-Vpg PU A OUT 27-Vphg Pickup A
10313 27-Vpg PU B OUT 27-Vphg Pickup B
10314 27-Vpg PU C OUT 27-Vphg Pickup C
No. Information Type of In-
formation
Comments
